| Brand |
Hikvision |
| Operation System |
Linux |
| Display Dimensions |
4.3-inch |
| Resolution |
272 × 480 |
| Type |
LCD |
| Operation method |
Capacitive touch screen |
| Pixel |
2 MP |
| Lens |
× 2 |
| Video standard |
PAL (Default) and NTSC |
| Wired network |
10 M/100 M self-adaptive |
| Wi-Fi |
Support |
| PoE |
IEEE802.3at, standard PoE |
| Network Interface |
1 |
| RS-485 |
1 |
| Wiegand |
1 |
| Lock output |
1 |
| Exit button |
1 |
| Door contact input |
1 |
| TAMPER |
1 |
| USB |
1 |
| Card capacity |
3,000 |
| Face capacity |
1,500 |
| Fingerprint capacity |
3,000 |
| Event capacity |
150,000 |
| Card Type |
EM card |
| Card reading frequency |
125 KHz |
| Face recognition duration |
＜ 0.2 s |
| Face recognition accuracy rate |
＞ 99% |
| Face recognition distance |
0.3 to 1.5 m |
| Fingerprint recognition duration |
＜1 s |
| Power Supply |
Power input: Power interface (power adapter included, 12 VDC/1 A) or PoE (37 to 57 VDC/0.6 A)
Power output: Power supply for door lock, 12 VDC/1 A (only when the device is powered by PoE supporting powering supply for door lock) |
| Working temperature |
-30 °C to 60 °C (-22 °F to 140 °F) |
| Working humidity |
0 to 90% (No condensing) |
| Dimensions |
91.3 mm × 181.3 mm × 24.5 mm (3.59" × 7.14" × 0.96") |
| Installation |
Wall Mounting |
| Protective level |
IP65 |
| Supported languages |
English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil), Korean |
| Weight |
Gross weight: 0.93 kg (2.05 lbs)
Net weight: 0.36 kg (0.79 lbs) |
| Face anti-spoofing |
Support |
| Audio prompt |
Support |
| Time synchronization |
Support |
